Model | Model | C220 | |
Type | Network IP Camera | ||
Camera
|
Camera Pixel | 4MP (2560×1440) | |
Camera Solution | GK7205V300+K06 | ||
Image Sensor | 1/2.7″ Progressive Scan CMOS | ||
Lens | 4mm @ F2.0, Horizontal 95° | ||
Lens Interface | M12 | ||
Minimum Illumination | 0.012Lux (color mode); 0Lux (IR light on) | ||
Infrared Light | 2 | ||
Infrared Wavelength | 850nm | ||
Day/Night Mode | ICR infrared filter | ||
Infrared Night Vision Distance | 30m | ||
Video | Max Image Size | 2560×1440 (4MP), supports dual-stream | |
Frame Rate | 25fps | ||
Video Compression Standard | H.265/H.265+ Main Profile | ||
Video Compression Bitrate | Up to 2048kbps | ||
Stream Type | Variable bitrate | ||
Dual Stream | Main stream: 2560×1440, Sub stream: D1 (640×360) | ||
Image Settings | Brightness, Contrast, Sharpness, Saturation (adjustable via NVR and APP) | ||
Audio | Audio Input | Built-in microphone | |
Audio Output | None | ||
Audio Compression Standard | G.711A | ||
Camera Features | White Balance | Auto | |
Gain Control | Auto | ||
Digital Noise Reduction | 3D Digital Noise Reduction | ||
Backlight Compensation | Supported | ||
Wide Dynamic Range | Supported (Digital and Hardware) | ||
Strong Light Suppression | Supported | ||
Network |
Wired Interface | 1 RJ45 10M/100M adaptive Ethernet port | |
Protocols | IPv4, TCP, UDP, RTSP, RTP, DHCP, NTP, ONVIF | ||
Software | ZOSI Smart (Android/IOS), AVSS (PC/MacBook) | ||
Browser | Not supported | ||
Common Features |
Intelligent Detection | Motion Detection, Human-Form Detection | |
Voice Function | One-way audio | ||
Night Vision | Black and white night vision | ||
Recording | Continuous recording, Alarm recording | ||
General |
Power Supply | POE IEEE 802.3af 48V, DC12V | |
Operating Temperature and Humidity | -10℃ to 60℃, humidity less than 95% (non-condensing) | ||
Memory Card Support | Not Supported | ||
Power Consumption | 6W MAX | ||
Protection Level | IP66 (waterproof and dustproof) | ||
Composition | Metal |
